The specific mechanics of making a chip are already insanely complicated, requiring atom-scale accuracy and some of the most precise manufacturing tools ever created, but the current method has its limits. This process has been in use for nearly 15 years, and it’s running out of steam. Parts of the transistors on a chip are now on the order of 7 to 10 nanometers in size, far smaller than the 193nm UV light used to create them.

Manufacturers needed to redesign the process if we were going to keep making better and faster chips, and the new process is extreme ultraviolet lithography, or EUV. Companies have been working for years to develop this next step in chipmaking, and we are just seeing the first devices made with EUV coming to market.

To learn more about this process, I went to two of Intel’s manufacturing facilities where they are developing EUV to see the machines in person, and learn more about this extreme manufacturing.

An evolutionary leap, EUV still projects a chip blueprint onto silicon, but it uses light with an incredibly small wavelength to do so, the better for creating minuscule features.

At these tiny wavelengths, the UV light is absorbed by nearly everything, and it can’t be generated with a typical laser. The process is far more exotic, involving liquid metal and high energy plasma. The technical challenges are immense, but the payoff is a leap in the speed and energy efficiency of our devices.
